Flexible Printed Circuit Boards make use of printed circuitry based on flexible foundation material. As a result, flex circuits can be shaped to fit where no other design can, providing customers with the freedom to choose whatever shape and orientation best suits their design while maintaining the precision and convenience of traditional printed circuit boards. In terms of common applications, flex boards are used in portable electronics, hard drives, printers, and as replacements for wire harness assemblies.

• Sample Boards

Layer(s): 2

Material: PI

Board Thickness: 0.236mm

Surface Mount: H.A.L. / FR4 1.5mm

Trace/Space: 5 / 5mil

Layer(s): 2

Material: PI

Board Thickness: 0.5mm

Surface Mount: H.A.L. / PET 0.15mm

Trace/Space: 6 / 6mil

Layer(s): 2

Material: PI

Board Thickness: 0.26mm

Surface Mount: Immersion Gold

Trace/Space: 6 / 6mil

Layer(s): 2

Material: PI

Board Thickness: 0.25mm

Surface Mount: Immersion Gold

Trace/Space: 6 / 6mil

Layer(s): 2

Material: PI

Board Thickness: 0.26mm

Surface Mount: Immersion Gold

Trace/Space: 5 / 5mil

Layer(s): 1

Material: PI

Board Thickness: 0.135mm

Surface Mount: H.A.L.

Cover Layer: 25 / 25um

Layer(s): 2

Material: PI

Board Thickness: 0.23mm

Surface Mount: Immersion Gold

Cover Layer: 25 / 25um

Layer(s): 2

Material: PI

Board Thickness: 0.25mm

Surface Mount: Immersion Gold

Trace/Space: 6 / 6mil

Layer(s): 1

Material: PI

Board Thickness: 0.13mm

Surface Mount: Immersion Gold / PET 0.17mm

Trace/Space: 4 / 3.6mil

Layer(s): 1

Material: PI

Board Thickness: 0.3mm

Surface Mount: H.A.L. / PET 0.15mm

Trace/Space: 7 / 7mil

Layer(s): 1

Material: PI

Board Thickness: 0.125mm

Surface Mount: H.A.L.

Cover Layer: 25 / 25 um

Layer(s): 1

Material: PI and LPI Soldermask

Board Thickness: 0.125mm

Surface Mount: Immersion Gold / PVC 0.2mm

Cover Layer: 25 / 25um

Layer(s): 2

Material: PI

Board Thickness: 1.69mm

Surface Mount: Immersion Gold

Trace/Space: 8 / 4mil
